5 Station Jungle Gym - Compact Cable Machine [Synergy Series]

Synergy Series 5 Station Jungle Gym TB94 - Compact Commercial Cable Machine

Five Stations, Five Independent Stacks | 2.7m Deep Footprint | 10-Year Frame Warranty

The Synergy 5 Station Jungle Gym TB94 is the four-station tower with a fifth station bolted on: a four-station cable tower - lat pulldown, seated low row, high pulley and a second pulldown/row position - plus an adjustable-height cable column on an outrigger arm for single-arm rows, curls, face pulls, woodchops and pull-throughs.

Two 80kg stacks and three 100kg stacks sit inside the frame with the cables routed through the uprights, so five members train at once with nothing shared. Because it runs long rather than wide - 5.6m long on only 2.7m of depth - it sits against a wall or down a lane where a square jungle won't go.

Built on heavy commercial steel at 1350kg, it opens a full cable zone in a single delivery for floors that need station count without the square footage.

Key Features

• Five cable stations: four-station tower plus an adjustable cable column on an outrigger arm.
• Five independent weight stacks: 2 x 80kg and 3 x 100kg - five users at once, no shared load.
• Stack upgrades: each stack upgradeable to 140kg at $10 per kilogram on made-to-order builds.
• Adjustable-height cable column: low, mid and high work from one pulley for the widest exercise range.
• Lat pulldown with thigh hold and low row with foot plates: braced positions for heavy vertical and horizontal pulling.
• Long, narrow footprint: 5.6m x 2.7m - fits against a wall or along a lane.
• Cables routed inside the uprights: a clean, enclosed look with nothing to snag.
• 1350kg commercial steel frame: planted and rattle-free under five users.
• Custom colours: 16 frame colours and 12 upholstery colours available on made-to-order builds.

Technical Specifications

Ideal For

• Commercial gyms placing a cable zone along a wall or down a lane
• 24/7 clubs and franchises maximising members-per-square-metre
• Hotels, universities and corporate gyms covering five stations without five machines
• Strength facilities and PT studios running circuits and small group training

Warranty

FAQs

What exercises can I do on it?
Lat pulldowns in every grip, seated rows, straight-arm pulldowns, pushdowns and overhead extensions on the high pulley, and the full cable-column menu - curls, face pulls, upright rows, lateral raises, single-arm rows, woodchops, pull-throughs and cable crunches.

Can five people really use it at the same time?
Yes - each station has its own stack and its own pulley path, so nothing is shared. Five users, five workouts, no waiting.

TB94 or TB82 - which 5 station should I choose?
The TB94 runs long and narrow with a cable column as its fifth station - best against a wall. The TB82 is a wider layout with an adjustable crossover and a dip and knee raise station. Send us your floor plan and we'll tell you which fits.

How much space and ceiling height do I need?
The frame is 5600 x 2700mm and stands 2550mm tall. Allow a user's working space along the open side - roughly a metre - and check ceiling clearance above the pulldown stations.

Can I upgrade the weight stacks?
Yes - on made-to-order builds each stack can be increased to 140kg at $10 per kilogram. Get in touch to spec it.

Can I customise the frame and upholstery?
Yes - made-to-order builds are available in 16 frame colours and 12 upholstery colours on an 8-12 week lead time. See the full colour chart below.

Do you offer delivery and installation?
Yes - Australia-wide delivery, with professional installation through our own technician team in Sydney. At 1350kg across two crates, this is a machine our team should assemble, level and cable. Contact us to discuss freight access and site requirements.

Delivery & Installation

Australia-wide delivery on a 1350kg multi-station machine, with professional installation available through our own technician team in Sydney. Contact us for a full quote including freight, installation and customisation support.

Commercial Fit-Outs & Bulk Orders

Outfitting a gym, studio or facility? Contact us for our full commercial catalogue, bulk pricing and a free consultation.

Shop More: Synergy Series | Multi-Function Machines | Compare: 4 Station TB66 | Compare: 5 Station TB82
Complete Your Setup: Cable Attachments | Gym Flooring
Browse Full Range: Commercial Gym Equipment

Five stations down one wall - the cable zone that fits where a square jungle won't.

Made To Order

RELOAD By Fitness Hero
Commercial Grade custom made to order products

You can now design your own custom made equipment to suit your own requirements. Simply let us know the colour or finish you would like on the products and we will do the rest.

Once an order has been placed, your equipment will be manufactured upon request. This process generally takes around 14 days depending on the size of each product.

Once the production is finished, it can take 4-6 weeks to be delivered to Sydney. Once it has arrived in our warehouse, we will arrange shipment to your location. Prior arrangement can also be made to ship items direct to you.

Estimated start to finish process: 8 - 12 weeks

Custom Design

Some of our ranges are fully colour customisable to suit your needs - 16 frame colours and 12 upholstery colours. Just get in touch when ordering to let us know which colour you require and we will do the rest.

Weight stack upgrades: each stack can be increased to 140kg at $10 per kilogram.

Bulk orders: if you have an enquiry regarding multiple items, please contact us as we may be able to provide a bulk discount. If you need advice on building a home gym, studio or commercial gym, we can also provide a free consultation.

Our commercial grade equipment also comes with a 10-year warranty!

• FRAME: 10 YEARS
• GUIDE RODS & BEARINGS: 3 YEARS
• UPHOLSTERY & PARTS: 12 MONTHS

Please reach out to our customer service if you have any questions or require some advice & one of our friendly staff members will be happy to help you.
